Compare Products
Applications
Harsh Environment Power Control Instrumentation
Harsh Environment Power Control Instrumentation
Harsh Environment Power Control Instrumentation
Brand
PermaLife®
PermaLife®
PermaLife®
CSA Listings
CSA FT4
-
FT4
Class
-
Class 1E Nuclear
-
Concstruction - Metallic Shield
-
5 mil helically applied tinned copper tape with 20% overlap
-
Construction - Barrier Tape
Flame barrier tape(s
Flame barrier tape(s)
Flame barrier tape(s)
Construction - Conductor
Bare copper (tinned copper also available), class “B” compressed strand (compact strand also available)
Bare copper (tinned copper also available), class “B” compressed strand (compact strand also available)
Bare copper (tinned copper also available), class “B” compressed strand (compact strand also available)
Construction - Conductor Shield
Permashield® conductor shield (non-conducting stress control layer)
Permashield conductor shield (non-conducting stress control layer)
Permashield® conductor shield (non-conducting stress control layer)
Construction - Insulation
Proprietary Kerite® discharge resistant insulation
Proprietary Kerite discharge resistant insulation
Proprietary Kerite® discharge resistant insulation
Construction - Insulation Shield
Thermoset semiconducting layer
Thermoset semiconducting layer
Thermoset semiconducting layer
Construction - Jacket
Flexible, thermoset low smoke zero halogen (LSZH)
Hypalon black heavy-duty chlorosulfonated polyethylene (HD-CSPE)
Flexible, thermoset low smoke zero halogen (LSZH)
Construction - Metallic Shield
5 mil helically applied tinned copper tape with 20% overlap
-
5 mil helically applied tinned copper tape with 20% overlap
Description
PermaLife medium voltage is a jacketed single conductor power cable designed for applications in Nuclear Power Generating Plants and Substations. It is intended for use in harsh and demanding environments and qualified for Class 1E applications (LOCA Qualified). It may be installed indoors or outdoors in trays, ducts, conduits, direct burial, or aerial applications to perform a variety of power functions. (NU16_A_Kerite)
PermaLife® medium voltage is a jacketed single conductor power cable designed for applications in Nuclear Power Generating Plants and Substations. It is intended for use in harsh and demanding environments and qualified for Class 1E applications (LOCA Qualified). It may be installed indoors or outdoors in trays, ducts, conduits, direct burial, or aerial applications to perform a variety of power functions. (NU16_E)
PermaLife medium voltage is a jacketed single conductor power cable designed for applications in Nuclear Power Generating Plants and Substations. It is intended for use in harsh and demanding environments and qualified for Class 1E applications (LOCA Qualified). It may be installed indoors or outdoors in trays, ducts, conduits, direct burial, or aerial applications to perform a variety of power functions (NU16_C)
Market Served
Nuclear
Nuclear
Nuclear
Performance Standards
ICEA S-97-682 and S-93-639 or S-68-516 and AEIC CS-6 • Class 1E qualified with IEEE 383-1974/2003 and IEEE 323-1974/2003 – Nuclear qualified with a minimum 60 year thermal life expectancy at 90°C – Radiation resistant (up to 220 megarads) • IEEE 383-1974 vertical tray flame test and IEEE 1202 vertical tray flame test • 10 CFR Appendix B • Full traceability • ICEA standard S-93-639
Cable passes IEEE 383-1974 as modified by NRC. Reg. Guide 1.131 vertical tray flame test and IEEE 1202 vertical tray flame test
ICEA S-97-682 and S-93-639 or S-68-516 and AEIC CS-6 • Class 1E IEEE 383-1974/2003 and IEEE 323-1974/2003 • IEEE 383-1974 and IEEE 1202 • 10 CFR Appendix B • Full traceability • ICEA standard S-93-639
Product Category
Power
Power
Power
Temperature
90ºC
90ºC
90ºC
UL Listings
UL 1685
-
UL 1685
Volts
600
600
600
